Getting Started
How to install Yale Linus® Smart Lock on your Yale Linus® Adjustable Cylinder.
FAQ's
Will the adjustable cylinder fit my door?
The adjustable cylinder aims to be a one size fits all solution for DIN/euro cylinder locks. As such the internal length can be extended from 30mm to 65mm by 5mm increments. The external length can be extended from 30mm to 60mm by 5mm increments also.
How many keys do I get with the adjustable cylinder?
Two keys will be delivered with the cylinder.
What tools do I need to assemble the cylinder?
The cylinder is assembled and fitted with Allen key. These are included within the pack with the adjustable cylinder. You then also need a Philips screwdriver to remove the bolt that holds the cylinder in the door (not included in the kit).
Can I get spare keys for the adjustable cylinder?
Yes, you can call 800 YALE (UAE) / +971 800 9253 (International) to request for a spare key.
How long is the warranty?
1 year.
What cylinder style does the adjustable cylinder work with?
The adjustable cylinder works with DIN style/euro cylinders.
Does it come in any other finishes?
No, it comes in one finish - this is called Satin Nickel.
Do I have ro remove my escutcheon?
No you do not need to remove your escutcheon. When you measure you door size simply include the escutcheon in your measurements and build the adjustable cylinder to fit this size.
However, when it’s time to fit your cylinder the escutcheon needs to be removed.
