Specifications:
- Certified for doors of up to 1000mm door width
- Minimum door thickness: 38mm
- Suitable for doors up to 135kgs
- Reversible for 38 to 45mm thick doors
Features:
- Patented, 3 dimensional hinges
- Suitable for aluminium, metal and timber doors
- Fire rated
- Symmetric design (reversible)
- Zinc alloy internal and external body
- Resistant to oxidation due to the external zinc zamak case
- Fluid sliding mechanism and 3D adjustable with a 5mm allen key
1131s Hinges
Specifications:
- Certified for doors of up to 1000mm width
- Minimum door thickness: 38mm
- Suitable for doors up to 120kgs
- Tested for 200,000 cycles
- Reversible for 38 to 46mm thick
Features:
- Patented, 3 dimensional hinges
- Suitable for aluminium, metal and timber doors
- Fire rated and CE certified
- Symmetric design (reversible)
- Galvanized steel covers
- Zinc alloy internal and external body
- Resistant to oxidation due to the external zinc zamak case
- Fluid sliding mechanism and 3D adjustable with a 3mm allen key and 10mm hexagonal key
1230s Hinges
Specifications:
- Certified for doors of up to 1000mm width
- Minimum door thickness: 35mm
- Suitable for doors up to 70kgs
- Suitable for cladded side panels/walls upto 15mm thick
- Tested for 200,000 cycles
- Reversible for 35 to 45mm thick doors
Features:
- Patented and CE certified, 3 dimensional hinges
- Suitable for aluminium, metal and timber doors
- Symmetric design (reversible)
- Galvanized steel covers
- Zinc alloy internal and external body
- Resistant to oxidation due to the external zinc zamak case
- Fluid sliding mechanism and 3D adjustable with a 2.5mm allen key and 8mm hexagonal
1430 Hinges
Specifications:
- Certified for doors of up to 1000mm width
- Minimum door thickness: 28mm
- Suitable for doors up to 65kgs
Features:
- Patented, 3 dimensional hinges
- Suitable for aluminium, metal and timber doors
- Fire rated
- Symmetric design (reversible)
- Galvanized steel covers
- Zinc alloy internal and external body
- Resistant to oxidation due to the external zinc zamak case
- Fluid sliding mechanism and 3D adjustable with a 4mm allen key
1432 Hinges
Specifications:
- Minimum door thickness: 38mm
- Suitable for doors up to 215kgs
- Reversible for 38 to 45mm thick doors
- Tested for doors of up to 1000mm width
Features:
- Patented, 3 dimensional hinges
- Suitable for aluminium, metal and timber doors
- Symmetric design (reversible)
- Galvanized steel covers
- Zinc alloy internal body and aluminium external body
- Fluid sliding mechanism and 3D adjustable with a 5mm allen key
- Resistant to oxidation due to the external aluminium case
